Flat oval brass pipe indicates the brass tube whose section is oval and it’s flat. An oval is a curve resembling an egg or an ellipse. It is generally drawn by stage die and finished mould in sequence from round brass tube.
Features
Introduction of Flat Oval Brass Pipe
Flat oval brass pipe refers to a brass tube with a flat oval section. An oval is a curve resembling an egg or an ellipse. It is generally drawn by stage die and finished mould in sequence from a round brass tube.
We stock brass tube with a wall thickness of 1.6mm. The outside diameters we offer range from 9.35mm right up to 50.8mm
Available in lengths up to 5m, we can also supply this custom cut to your requirements.
Our stock is available in various sizes from 1/2" diameter to 2" diameter. As well as our standard stock lengths we can supply pieces cut to your exact requirements. Please note the tolerance on the maximum standard lengths is +/- 300mm. Tolerances on other special cut lengths is -0 + 3mm.
Features of Flat Oval Brass Pipe
Good electricity
Heat conduction
Good elongation
Being extruded and processed well
Good corrosion-resistance
Climate-hardiness
Alloy And Production Standard
- C26000, C27000, C27200, C28000, C38500, C68700 (ASTM B111 or ASME SB111)
- CuZn30, CuZn36, CuZn37, CuZn40, CuZn39Pb3, CuZn20Al2As (EN12451 or EN12449 or DIN)
- CZ106, CZ107, CZ108, CZ109, CZ110 (BS British Standard)
- C2600, C2700, C2720, C2800, C3560, C6870 (JIS Japanese Industrial Standards)
Chemical Composition
62.0≤Cu≤71.5 ; Zn Rem
Dimension/Size
Maximum outside diameter: 50.8mm
Maximum length: 4 meters
Applications of Flat Oval Brass Pipe
Flat oval brass pipe is not only used in kitchen and bathroom accessories but also in oval tube heat exchangers. These heat exchangers are more efficient than round tube heat exchangers, transferring heat from thermal fluid to cold fluid to reach the desired fluid temperature.
Water Supply
Brass pipes distribute potable water in residential, commercial, and industrial settings. Their resistance to corrosion makes them suitable for long-term water supply applications.
Heating Systems
Brass pipes, such as radiators and baseboard heaters, are frequently employed in heating systems. They efficiently transfer heat and can withstand high temperatures.
HVAC
Brass pipes are used in HVAC systems for refrigerant lines and condenser units. Their resistance to corrosion and ability to handle pressure make them ideal for this purpose.
Maintaining Brass Pipes
To ensure that your brass pipes last as long as possible, it is crucial to maintain them properly. You can keep them in good condition by inspecting them regularly, detecting and fixing any leaks promptly, cleaning them to remove mineral deposits when the buildup occurs, and using non-acidic cleaners to avoid corrosion.
Alloy C38010 vs C38500: Understanding the Differences
C38010
The Standard Extrusion Alloy Alloy C38010, is a widely used brass alloy for extrusions. This leaded alpha/beta brass alloy is noted for its ease of extrudability and bright golden appearance, a result of a small aluminium addition.
Key Characteristics of C38010:
Can be machined but not ideal
High corrosion resistance
Ideal for applications requiring minimal cold working
Predominantly used in extruded shapes such as angles, flats, and profiles under 9.53mm thickness
C38500
The Preferred Alloy for Cold Working C38500, often referred to as Architectural Bronze, is another popular brass alloy. Unlike C38010, this alloy is more suited for applications involving significant cold working.
Distinct Features of C38500:
Ideal for machining due to a small lead content
Enhanced resistance to corrosion and wear
Predominately used in applications where thickness is equal to 9.53mm or greater
Generally, supply in flat, rectangle or square sections only
Comparing C38010 and C38500 While both C38010 and C38500 are excellent choices for brass flat bars, their specific properties make them suitable for different applications. In generally from the same manufacturer there is visually limited to no difference in appearance. Some caveats to the above to consider:
- From the same manufacturer.
- Manufactured with the same method, e.g. drawn, extruded or continuous cast.
- Supplied from the same batches.
- Stored in the same conditions (material can age overtime in humid conditions even in storage).
Our Service
Guilin Lijia has professional Quality Control department, issuing test certificates for our qualified products in accordance with relevant standards. We also have experienced inspectors and professional inspection equipments, such as spectrum analyzer introduced from Switzerland, metallographic microscope, eddy current flaw detector, ultrasonic flaw detector, tension tester, hardness tester and hydrostatic testing machine etc.
If products have any problems, customers provide indubitable evidence, such as samples and pictures etc., QC department will handle the claim accordingly.
Each product is precisely test by professional technicians before leaving the factory to ensure the stable performance and high quality of China Ms Hollow Section Hot Dipped Galvanized Square Tube. Our solutions have national accreditation requirements for qualified, good quality products, affordable value, was welcomed by individuals all over the world. We are willing to cooperate with business friends from at home and abroad and create a great future together.
